D
$7$
$40°$
证明:
$\because OD$平分$∠ AOB,$
$\therefore ∠ BOD=∠ AOD。$
在$△ BOD$和$△ AOD$中,
$\begin{cases} OB=OA, \\ ∠ BOD=∠ AOD, \\ OD=OD, \end{cases}$
$\therefore △ BOD≌△ AOD(\mathrm{SAS}),$
$\therefore ∠ BDO=∠ ADO,$即$OD$平分$∠ BDA。$
又$\because PM⊥ BD,$$PN⊥ AD,$
$\therefore PM=PN。$
(1) 证明:过点$A$作$AH⊥ BC$于点$H。$
在$△ ABC$和$△ ADE$中,
$\begin{cases} BC=DE, \\ ∠ C=∠ E, \\ CA=EA, \end{cases}$
$\therefore △ ABC≌△ ADE(\mathrm{SAS}),$
$\therefore S_{△ ABC}=S_{△ ADE},$
$\therefore \frac{1}{2}BC· AH=\frac{1}{2}DE· AF。$
$\because BC=DE,$
$\therefore AH=AF。$
又$\because AF⊥ DE,$$AH⊥ BC,$
$\therefore GA$平分$∠ DGB。$
(2) 解:$\because △ ABC≌△ ADE,$
$\therefore AB=AD。$
在$\mathrm{Rt}△ ADF$和$\mathrm{Rt}△ ABH$中,
$\begin{cases} AD=AB, \\ AF=AH, \end{cases}$
$\therefore \mathrm{Rt}△ ADF≌\mathrm{Rt}△ ABH(\mathrm{HL}),$
$\therefore S_{△ ADF}=S_{△ ABH},$
$\therefore S_{\mathrm{四边形}DGBA}=S_{\mathrm{四边形}AFGH}=6。$
在$\mathrm{Rt}△ AFG$和$\mathrm{Rt}△ AHG$中,
$\begin{cases} AG=AG, \\ AF=AH, \end{cases}$
$\therefore \mathrm{Rt}△ AFG≌\mathrm{Rt}△ AHG(\mathrm{HL}),$
$\therefore S_{△ AFG}=S_{△ AHG}=3。$
$\because AF=\frac{3}{2},$
$\therefore \frac{1}{2}FG· \frac{3}{2}=3,$
解得 $FG=4。$
