$\sqrt{3} - 1$
$\frac{2\sqrt{65}}{3}$
$y = \frac{3\sqrt{3}}{4}x^2 - 3\sqrt{3}x + 4\sqrt{3}$
$\frac{2\sqrt{5}}{5}$
解:过点​$C$​作​$CF \perp AB$​于点​$F。$​设小正方形的边长为​$a(a > 0),$​
​$ $​则​$BC = 2a,$​点​$A$​到​$BC$​的距离​$h = 2a。$​
由勾股定理,得​$AB = \sqrt {(4a)^2 + (2a)^2} = 2\sqrt {5}a,$​
​$AC = \sqrt {(2a)^2 + (2a)^2} = 2\sqrt {2}a。$​
由三角形面积公式,得​$\frac {1}{2}AB ·CF = \frac {1}{2}BC ·h,$​
​$ $​即​$\frac {1}{2} ×2\sqrt {5}a ×CF = \frac {1}{2} ×2a ×2a,$​解得​$CF = \frac {2\sqrt {5}}{5}a。$​
​$ $​在​$Rt\triangle AFC$​中,​$AF = \sqrt {AC^2 - CF^2} = \sqrt {(2\sqrt {2}a)^2 - (\frac {2\sqrt {5}}{5}a)^2} = \frac {6\sqrt {5}}{5}a。$​
∴​$tan ∠BAC = \frac {CF}{AF} = \frac {1}{3},$​​$sin ∠BAC = \frac {CF}{AC} = \frac {\sqrt {10}}{10},$​​
$cos ∠BAC = \frac {AF}{AC} = \frac {3\sqrt {10}}{10}。$​
证明: (1)$\because AP$、$BP$分别切$\odot O$于点$A$、$B,$
$\therefore \angle PAO = \angle PBO = 90^\circ。$
$\because OP = OP,$$OA = OB,$
$\therefore Rt\triangle PAO \cong Rt\triangle PBO(HL)。$
$\therefore \angle AOP = \angle BOP,$即$\angle AOP = \frac{1}{2}\angle AOB。$
$\because \overset{\frown}{AB} = \overset{\frown}{AB},$
$\therefore \angle ADB = \frac{1}{2}\angle AOB。$
$\therefore \angle ADB = \angle AOP。$
(2)过点$O$作$OH \perp DE$于点$H,$则$BH = DH。$
在$Rt\triangle OAP$中,$AP = 10,$$\tan \angle AOP = \frac{1}{2},$
$\therefore OA = 2AP = 20。$
$\because \angle PAO = 90^\circ,$$C$为$OP$的中点,
$\therefore PC = OC = AC。$
$\therefore \angle AOP = \angle OAC。$
由(1),得
$\angle AOP = \angle ADB = \angle BOP,$
$\therefore \angle OAC = \angle ADB。$
$\therefore DE // OA。$
$\therefore \angle AOP = \angle E = \angle BOP。$
$\therefore BE = OB = 20,$$\tan E = \tan \angle AOP = \frac{1}{2}。$
在$Rt\triangle EHO$中,$\frac{OH}{EH} = \frac{1}{2}。$
设$OH = k,$则$EH = 2k,$
$\therefore BH = 2k - 20。$
在$Rt\triangle BHO$中,$BH^2 + OH^2 = OB^2,$
即$(2k - 20)^2 + k^2 = 20^2,$解得$k = 16$($k = 0$舍去)。
$\therefore BH = 12。$
$\therefore BD = 2BH = 24。$
$\therefore DE = BD + BE = 44。$
